Tip film
Video RAW/SRAW: 8K DCI (17:9)/4K DCI (17:9)11
Video MP4: 8K DCI/UHD (17:9/16:9), 4K DCI/UHD (17:9/16:9), 2K/Full HD (17:9/16:9)
8K/4K/2K/Full HD: XF-HEVC S/H.265, audio: PCM liniar/AAC
4K/2K/Full HD: MPEG-4 AVC S/H.264, audio: PCM liniar/AAC
8K RAW, 4K RAW: CRM pe 12 biti, audio: PCM liniar/AAC
Modul de filmare cu redare accelerata 8K/4K/Full HD
Format film
RAW (Light) (17:9) 8192 x 4320 (59,94, 50, 29,97, 25, 24, 23,98 cps)
RAW (Standard) (17:9) 8192 x 4320 (29,97, 25, 24, 23,98 cps)
SRAW (Standard, Light) (17:9) 4096 x 2160 (59,94, 50, 29,97, 25, 24, 23,98 cps)
8K DCI (17:9) 8192 x 4320 (29,97, 25, 24, 23,98 cps) 2-3 tipuri intracadru sau Long GOP
8K UHD (16:9) 7680 x 4320 (29,97, 25, 23,98 cps) 2-3 tipuri intracadru sau Long GOP12
4K DCI (17:9) 4096 x 2160 (119,9, 100, 59,94, 50, 29,97, 25, 24, 23,98 cps) 3 tipuri intracadru sau Long GOP
4K UHD (16:9) 3840 x 2160 (119,9, 100, 59,94, 50, 29,97, 25, 23,98 cps) 3 tipuri intracadru sau Long GOP
2K DCI (17:9) 2048 x 1080 (239,76, 200, 119,9, 100, 59,94, 50, 29,97, 25, 24, 23,98 cps) intracadru sau Long GOP
Full HD (16:9) 1920 x 1080 (239,76, 200, 119,9, 100, 59,94, 50, 29,97, 25, 23,98 cps) intracadru sau Long GOP
Inregistrare de filme HDR pana la 59,94p in modurile de rezolutie normala 4K DCI/UHD, 2K DCI/UHD, Full HD
Inregistrare de filme HDR pana la 29,97p in modurile de rezolutie fina 4K DCI/UHD, 2K DCI/UHD, Full HD13
Esantionare culori (inregistrare interna)
8K/4K/2K/Full HD - YCbCr 4:2:0 sau YCbCr 4:2:2 pe 8 biti sau 10 biti
Canon Log
Imagine personalizata:
C1: Canon 709
C2: Canon Log 2
C3: Canon Log 3
C4: PQ
C5: HLG
C6: BT.709 Standard
C7 – C20: definit de utilizator
Stiluri de imagine: Automat, Standard, Portret, Peisaj, Detalii fine, Neutru, Fidel, Monocrom, Definit de utilizator (x3)
Filmare la rata mare de cadre
Video MP4:
4K – DCI 4096 x 2160/UHD 3840 x 2160 la 119,9/100 cps
2K – DCI 4096 x 2160/UHD 3840 x 2160 la 239,76/200/119,9/100 cps
Full HD 1920 x1080 la 239,76/200/119,9/100 cps15
Captura de cadre
Este posibila captura de cadre din filme 8K DCI ca fotografii JPEG de 35,4 megapixeli
Este posibila captura de cadre din filme 8K UHD, ca imagini statice JPEG de 33,2 megapixeli
Este posibila captura de cadre din filme 4K DCI ca fotografii JPEG de 8,8 megapixeli
Este posibila captura de cadre din filme 4K UHD, ca imagini statice JPEG de 8,3 megapixeli
(HEIF posibil numai cand este selectat HDR PQ)16
Inregistrarea duala (fotografii si filme):
Filme:
Format principal de inregistrare: XF-AVC S YCC420 pe 8 biti
Dimensiune de inregistrare a filmelor: Full HD (normal) la 29,97p/25p (LGOP)
Mod de declansare pentru fotografii (numai JPEG la rezolutia de 8K (7680 x 4320) si raport de aspect: aprox. 16:9):
Viteza ridicata (max. aprox. 7,5 fotografii/sec. (NTSC), max. aprox. 6,2 fotografii/sec. (PAL))
Viteza redusa (max. aprox. 5 fotografii/sec. (NTSC), max. aprox. 4,1 fotografii/sec. (PAL))
Fotografiere unica17
Rata de biti/Mbps
CRM:
8K RAW Standard (29,97p/25,00p/24,00p/23,98p): aprox. 2600 Mbps
8K RAW Light (59,94p/50,00p): aprox. 2600 Mbps
8K RAW Light (29,97p): aprox. 1670 Mbps
8K RAW Light (25p): aprox. 1400 Mbps
8K RAW Light (24,00p/23,98p): aprox. 1340 Mbps
4K SRAW Standard (59,94p): aprox. 1860 Mbps
4K SRAW Standard (50p): aprox. 1550 Mbps
4K SRAW Standard (29,97p): aprox. 930 Mbps
4K SRAW Standard (25,00p/24,00p/23,98p): aprox. 780 Mbps
4K SRAW Light (59,94p): aprox. 840 Mbps
4K SRAW Light (50p): aprox. 700 Mbps
4K SRAW Light (29,97p): aprox. 420 Mbps
4K SRAW Light (25,00p/24,00p/23,98p): aprox. 350 Mbps
MP4 8K DCI/UHD Normal:
XF-HEVC S YCC422 pe 10 biti
Calitate ridicata intracadru 24p/23,98p: aprox. 1920 Mbps
Standard intracadru 25p: aprox. 1500 Mbps
Light intracadru 25p: aprox. 1000 Mbps
Standard LGOP 25p: aprox. 540 Mbps
XF-HEVC S YCC420 pe 10 biti Standard LGOP
29,97p/25,00p/24,00p/23,98p: aprox. 400 Mbps
MP4 4K DCI/UHD fina/normala (supraesantionat din 8K/fara supraesantionare):
XF-HEVC S YCC422 pe 10 biti Standard LGOP
29,97p/25,00p/24,00p/23,98p: aprox. 135 Mbps
XF-HEVC / XF-AVC S S YCC420 pe 10 biti/8 biti Standard LGOP
29,97p/25,00p/24,00p/23,98p: aprox. 100 Mbps
XF-AVC S YCC422 pe 10 biti
Calitate ridicata intracadru 25p: aprox. 500 Mbps
Standard intracadru 25p: aprox. 375 Mbps
Light intracadru 25p: aprox. 250 Mbps
Standard LGOP 29,97p/25,00p/24,00p/23,98p: aprox. 150 Mbps
MP4 4K DCI/UHD Normal (fara supraesantionare):
XF-HEVC S YCC422 pe 10 biti Standard LGOP
119,9p/100p: aprox. 450 Mbps
59,94p/50,00p: aprox. 225 Mbps
XF-HEVC / XF-AVC S S YCC420 pe 10 biti/8 biti Standard LGOP
119,9p/100p: aprox. 300 Mbps
59,94p/50,00p: aprox. 150 Mbps
XF-AVC S YCC422 pe 10 biti
Calitate ridicata intracadru 50p: aprox. 1000 Mbps
Standard intracadru 100p: aprox. 1500 Mbps
Standard intracadru 50p: aprox. 750 Mbps
Light intracadru 100p: aprox. 1000 Mbps
Light intracadru 50p: aprox. 500 Mbps
Standard LGOP 100p: aprox. 500 Mbps
Standard LGOP 50p: aprox. 250 Mbps
MP4 2K DCI/Full HD fina/normala (supraesantionat din 4K/fara supraesantionare):
XF-HEVC S YCC422 pe 10 biti Standard LGOP
59,94p/50,00p/29,97p/25,00p/24,00p/23,98p: aprox. 50 Mbps
XF-HEVC / XF-AVC S S YCC420 pe 10 biti/8 biti Standard LGOP
59,94p/50,00p/29,97p/25,00p/24,00p/23,98p: aprox. 35 Mbps
XF-AVC S YCC422 pe 10 biti
Standard intracadru 25p/50p: aprox. 125/250 Mbps
Standard LGOP 59,94p/50,00p/29,97p/25,00p/24,00p/23,98p: aprox. 50 Mbps
MP4 2K DCI/UHD Normal (fara supraesantionare):
XF-HEVC S YCC422 pe 10 biti Standard LGOP
239,76p/200p: aprox. 200 Mbps
119,88p/100p: aprox. 100 Mbps
XF-HEVC / XF-AVC S S YCC420 pe 10 biti/8 biti Standard LGOP
239,76p/200p: aprox. 140 Mbps
119,88p/100p: aprox. 70 Mbps
XF-AVC S YCC422 pe 10 biti
Standard intracadru 200p: aprox. 1000 Mbps
Standard intracadru 100p: aprox. 500 Mbps
Standard LGOP 200p: aprox. 200 Mbps
Standard LGOP 100p: aprox. 100 Mbps
Film proxy (2K-DCI normal/Full HD normal)
XF-HEVC S YCC420 pe 10 biti/XF-AVC S YCC420 pe 8 biti Standard LGOP
59,94p/50p/29,97p/25p/24p/23,98p: aprox. 16 Mbps
XF-HEVC S YCC420 pe 10 biti/XF-AVC S YCC420 pe 8 biti Light LGOP
59,94p/50p/29,97p/25p/24p/23,98p: aprox. 9 Mbps
Inregistrare pe doua carduri Da (inclusiv inregistrarea fisierelor proxy)
Afisaj HDMI
Redare numai la monitor extern (redarea imaginilor si a informatiilor de inregistrare, imaginile sunt inregistrate pe card)
Redare pe ecranul aparatului foto si pe monitor extern (inregistrare simultana pe aparatul foto si pe dispozitiv de inregistrare extern, ecranul aparatului foto afiseaza imagini cu informatii de fotografiere)18
Iesire HDMI
Inregistrare 8K RAW sau 4K SRAW ProRes prin HDMI19
4K (DCI) 59,94p/50p/29,97p/25p/24p/23,98p,
4K (UHD) 59,94p/50p/29,97p/25p/23,98p,
Full HD 59,94p/60i/59,94i/50p/50i
480p 59,94p
576p 50p
YCbCr 4:2:2 necomprimat, pe 10 biti, este posibila si redarea sunetului prin HDMI
Focalizare
Dual Pixel Intelligent AF cu detectarea ochilor/fetei si focalizare automata cu urmarire (oameni, animale si vehicule), Servo AF pentru filme, focalizare manuala
